Technical Specifications

LCD Display
LCD Panel: 17” TFT LCD (diagonal)
Resolution: 1280 × 1024
Brightness: 1000 cd/m²
Contrast Ratio: 1000:1
Viewing Angle: 85° / 85° / 80° / 80° (wide viewing angles)
Operating Temperature: 0°C ~ +50°C (upgradeable to -30°C ~ +80°C at extra cost)

Touch Screen
Touch Size: 17” diagonal
Touch Type: 5-wire resistive
Touch Resolution: 4096 × 4096

Chassis
Front Bezel: Thick rugged aluminum front bezel, rackmount type
Front Keypad:

• 1 × 2-button keypad (Power On/Off & Reset)

• 1 × 5-button keypad (Dimming function)
  Chassis Material: Heavy-duty steel construction
  Cooling: With cooler
  Ingress Protection: IP65 water-resistant front panel

Mounting Options
Rack Mount supported
VESA 75 wall mount supported

Motherboard
Mainboard Grade: Military-grade motherboard
Chipset & Processor:

• CPU Socket: LGA 1151

• Power Consumption: 35 watts

• CPU Withstand Temperature: up to 100°C

Memory
4GB DDR4 RAM (Options: 8GB / 16GB / 32GB)

Storage Device
1 × 500GB SATA slim HDD
Optional: 120GB / 240GB / 500GB SSD

Graphics
Intel® High Definition Graphics

I/O Ports
LAN: 2 × Gigabit Ethernet (10 / 100 / 1000 Mbps)
USB: 4 × USB 3.0 + 1 × USB 2.0 (front)
Video Output: 1 × VGA, 1 × HDMI, 1 × DisplayPort
COM Ports:

• 2 × RS232/422/485

• 2 × RS232
  Customized Options:

• COM 2: RS485 with Pin 1 as RTX–, Pin 2 as RTX+

• COM 4: with DC +12V output
  Audio: 1 × Line-in, 1 × Line-out, 1 × Mic-in
  PS/2: N/A

Power Supply
DC Input: 12V / 19V / 24V DC input
AC Power: External AC adapter, supports 90~264V 50/60Hz

Heater (Optional)
Patented heater module with temperature sensor to support boot-up at -40°C

Power Consumption
Total Power: Approx. 30~40W (excluding heater module, if any)

Environmental
Operating Temperature: 0°C ~ +50°C
Optional: Built-in patented heater module for boot-up at -40°C
Storage Temperature: -20°C ~ +60°C
Humidity: 0~95% relative humidity, non-condensing
Shock: Designed to meet MIL-STD-810F
Vibration: Designed to meet MIL-STD-810F
