TECHNICAL SPECIFICATIONS

LCD Display

• Display Size: 19” TFT LCD diagonal

• Resolution: 1280 x 1024

• Brightness: 1000 cd/m²

• Contrast Ratio: 1000:1

• Aspect Ratio: 4:3

• Display Colors: 16.7M

• LED Backlight: LED backlighting

• Viewing Angle: 170° (H) / 160° (V)

• Color Depth: 16.7 million

Mechanical

• EIA Standard: EIA-301E, 2U rackmount

• Material: Heavy-duty AISI-304 stainless steel, anti-corrosion treated

• Handle Grip: Equipped for easy pull-out operation

• Color: Semi-gloss black

• Weight: Approx. 13 kg (25 lbs)

• Dimensions:

  • Including slide rail: 465 (W) × 88.9 (H) × 562 (D) mm

  • Chassis only: 465 (W) × 88.9 (H) × 485 (D) mm

Protective Glass

• Protection: Built-in strengthened ruggedized glass

• Touch Function: Optional

• Impact Rating: Compliant with IK07 standard

Keyboard & Touch Pad

• Keyboard Type: Military-grade IP68 waterproof keyboard

• Keys: 104 keys with 24 function keys

• Key Material: Silicone rubber

• Backlight: LED backlit

• Built-in Touch Pad: Yes

• Interface: USB 2.0

• Transfer Speed: 480 Mbps

• Operating Voltage: DC 5V

• OS Compatibility: Windows 10 / Linux

Smart Card Reader

• Standards: ISO-7816-3, T=0, T=1

• Compatible Cards:

  • SLE4418 / 4428

  • SLE4432 / 4442

  • SLE4436 / 5536

  • I²C Memory Cards

Power Input

• Power Supply: AC 90~264V, 50/60 Hz

• Connector Type: D38999/20TC4PN (without mating side, available at extra cost)

• Power Consumption: < 25W

Environmental

• Operating Temperature: 0°C to +50°C

• Storage Temperature: -20°C to +60°C

• Humidity: 5% ~ 95% RH at 30°C, non-condensing

EMC / EMI & Reliability

• Salt Fog: Designed to meet MIL-STD-810G (test report available upon request)

• Vibration: Designed to meet MIL-STD-167-1 (test report available upon request)

• Shock: Designed to meet MIL-STD-901D (test report available upon request)

• EMI/EMC: Designed to meet MIL-STD-461E (CE102, CE106, CS101, CS103, CS104, CS105, CS114, CS115, CS116, RE101, RE102, RE103, RS101, RS103)
